Very Cheap Hot Selling LPG Powder Coating Oven
| Inside Size(mm) |
1200x1200x1700mm(LXWXH)(customized) |
| Outside size(mm) |
1500x1500x2000mm (LXWXH)(customized) |
| Wall panel |
Rock wool steel board,150 mm thick, |
| anti-flame and heat-insulation |
| Front door |
One set,1200*1700mm(W*H)(customized) |
| Fan |
1 set 0.55 kw high-temperatute fan,air flow capacity:600m3/h |
| Heating system |
1set of LPG burner,50000Kcal/h |
| stainless steel heat exchanger |
| max temp:220 ℃, heating time: 20-25 min (180-220℃). |
| Fan and burner box inner is 2 mm thick galvanized steel,interlayer 150mm thick rock wool,out is 1.2mm thick galvanized steel to keep heat |
| Control system |
Temperature alarm(With inductor in the oven) ,stop button,process setting system:could set baking time and temperature,when baking time arrive,stop automaticly |
| Total power |
0.55kw |
Powder Coating Oven with Top Rail:
Powder Coating Oven with Ground Rail:
Powder Coating Oven Components:
Factory
First Pre-sale services:
1). Select equipment model;
2). Design and manufacture according to client’s special requirement.
3). Train technical personal for clients.
Second Services during the sale:
1). Pre-check and accept products ahead of delivery.
2). Help clients to draft solving plans.
Third After-sale service:
1). Assist clients to prepare for the first construction scheme.
2). Install and debug the equipment.
3). Train the first-line operators.
4). Examine the equipment.
5). Take initiative to eliminate the trouble rapidly.
6). Provide perfect service.
7). Provide technical exchanging
Fourth Overseas Installiation Service
If the customers need overseas installiation service, we can send professional engineer to install for customers in your workshops but need to charge the cost.
1.What's the size of your products?
The size is according to the customer's workpiece.
2.What information do we need to offer if we want you to design for us?
Please inform your size of the workpiece and workplace,your output, heating system(LPG,diesel or electric), surface condition, also better if you may let us know your production process.
3.What payment terms do you accept?
We accept T/T, irrevocable L/C at sight.
4.Can you install for us?
Yes, we can supply installation overseas service, but the cost will be on you.
5.How long is your production time?
30-35 days after receipt of deposit, it depends on the size of the product.
